PL8310M single port network port

Description

Fiber port: 1 gpon interface, sc single mode / single fiber, downstream rate 2.5 gbps, upstream rate 1.25 gbps

Wavelength emission: 1310nm, receiving 1490nm

Optical fiber interface: SC / PC

Receiving sensitivity: <-28dbm (1490nm)

Wireless LAN: IEEE802.11b / g / n, 300 mbps, a built-in antenna

LAN: 1 10/100/1000 Mbps adaptive Ethernet port, full / half duplex, rj45 interface

Transmission rate: The transmission rate can reach 900 mbps or higher

DC power supply: 12 v 1a, external AC-DC power adapter

Button reset power

Power: ≤8W

Operating temperature: -5- + 55 humidity Operating humidity: 10-90% (no condensation)

Storage temperature: -30- + 60 humidity Storage humidity: 10-90% (no condensation)
